Ultrasound Neuromodulation
We can now turn on or off any brain region, without surgery
In 1958, neurologist F.J. Fry discovered that low-intensity ultrasound could affect the brain.1
Through a hole in a cat’s skull, he directed 20 seconds of focused ultrasound to the lateral geniculate nucleus (LGN), deep inside the hindbrain. The ultrasound administration temporarily blocked the cat’s neural response to a flash of bright light, as measured by electrodes on the visual cortex. 30 minutes after ultrasound administration, the cat’s response to light returned to normal.
In other words, Fry was able to use ultrasound to temporarily turn off the normal function of neurons in a specific part of the brain, without any long-term damage.
Since then, as ultrasound devices have become smaller and cheaper in the past two decades, transcranial focused ultrasound (tFUS) has been tested on many animals including humans, where it has been found to sometimes increase and sometimes decrease the neural excitability of any targeted brain region, depending on the settings of the ultrasound signal.
Ultrasound, at the relevant intensities, appears to be harmless to brain tissue. And modern devices can focus energy to few-millimeter-sized regions of the brain, at any depth, from noninvasive stimulation outside the head (i.e. no surgery needed.)
Turning up and down arbitrary brain regions noninvasively is a huge deal.
First of all, it means a safer approach to the disorders we already treat through invasive neuromodulation. Certain kinds of epilepsy or severe motor disorders can only be treated by implanting electrodes inside the brain or destroying the brain regions responsible for uncontrollable seizures or involuntary motions. If an ultrasound device could “turn down” or “turn up” the volume of neuron firing in those brain regions, the risk of surgical complications or brain damage would be far lower.
Second of all, it’s a huge opportunity for research. If you can “turn up” or “turn down” any brain region at will, safely enough to mess around with it on healthy human subjects, you can develop a functional atlas of the brain, where you find out exactly what each part is doing.
To date, we have only been able to do this by:
observing case studies of humans who happen to have brain damage in different regions
but of course you can’t ethically give people brain lesions
operating on animals to damage or stimulate parts of the brain
but of course animals can’t talk or reveal the effects of brain modifications on “higher” cognitive functions
observing patterns of blood flow activity in different brain regions (fMRI)
but this is observational rather than interventional — you’ll never know what would have happened counterfactually if those brain regions were activated or inactivated
inducing temporary “virtual lesions” through noninvasive brain stimulation via applying magnetic (rTMS) or electrical (tDCS) stimulation to the outside of the head.
but these methods can’t penetrate deep within the brain, so they are only usable for experimenting on the cerebral cortex and not the deeper structures that affect emotion, motivation, and memory.
Also, rTMS is a bulky fixed device, while tDCS electrode stimulation can be noisy and sensitive to head movements and hair interference.
Compared to these existing methods, neuromodulatory ultrasound (newly miniaturized and affordable thanks to MEMS innovations), if used to explore the brains of healthy humans, could vastly expand the range of our knowledge.
Ideally, a wearable ultrasound device would allow exploration of what happens when you experiment with different brain stimulation patterns during a variety of activities. Not just sitting in a chair in a lab or clinic with your head in a heavy device, but sleeping, exercising, having social interactions, and so on.
A wearable brain stimulator that could temporarily modulate neural activity would potentially be a platform for entirely new kinds of “therapies.”
Imagine if (as seems superficially plausible) you could get an anti-anxiety effect from “turning down the volume” on the amygdala.
Instead of having to take an anti-anxiety drug (which affects every part of the brain and body it reaches, needs to be metabolized, typically has side effects, and lasts for a fixed duration) you could simply alter only the brain regions you want to, for exactly as long as you want to.
Imagine a “thinking cap” that you could control, to tune your mental state at will to whatever you wanted it to be in a given situation.
This is a technology that could fundamentally change the human condition.
Could the right patterns of neuromodulation be used for cognitive enhancement? For reliably inducing the kinds of mental states that meditators report experiencing? For inducing positive emotions or pleasure, or blocking negative emotions or pain? There’s some reason to believe all of these might be possible.
In later posts I’ll go into more detail about what’s known about neuromodulatory ultrasound so far, how it works, what it’s been shown to do, what its risks are, and what we might reasonably hope to find from a systematic search for human enhancements.
Fry, F. J., H. W. Ades, and W. J. Fry. "Production of reversible changes in the central nervous system by ultrasound." Science 127.3289 (1958): 83-84.
